Colorado offers up to five available drive modes to help optimize your truck’s performance and adjust to challenging road conditions with the simple turn of a dial.
Created in collaboration with American Expedition Vehicles (AEV) — Colorado ZR2 Bison holds the best-in-class* record in ground clearance, breakover angle and underbody protection. It also features front and rear jounce control dampers, performance tested on desert racer Chad Hall’s Colorado ZR2 during the Best in the Desert series.
Flexible design features such as a mid-position tailgate capable of supporting 500 lbs., an available built-in 120-volt power outlet along with cargo bed lighting, and a convenient measurement tool built into the tailgate make it easy to see how Colorado offers better bed and tailgate functionality than any other competitor in its class.*
Shield and secure your cargo with an available truck bed cover made to provide the protection you need while still maintaining full access to the bed and everything in it.
Colorado offers convenience wherever you go with standard Google built-in,* Apple CarPlay®* and Android Auto™* to keep you connected, plus displays that put everything you need right where you need it - including segment-first available underbody cameras that offer a real-time forward- and rear-facing view beneath the truck.
Offering up to 17 available tie-downs and an available StowFlex tailgate, the eye-catching Colorado is ready to help you work hard so you can play harder.
The system wirelessly charges one compatible mobile device. Some phones have built-in wireless charging technology and others require a special adaptor/back cover. To check for phone or other device compatibility, visit my.chevrolet.com/learn or consult your carrier.
Starting From $31,900
Destination Charge $1,595
Gross Axle Wt Rating - Front 3500
Gross Axle Wt Rating - Rear 3600
Curb Weight - Front 2317
Curb Weight - Rear 1881
Gross Vehicle Weight Rating Cap 5800
Gross Combined Wt Rating 8700
Dead Weight Hitch - Max Trailer Wt. - TBD -
Dead Weight Hitch - Max Tongue Wt. - TBD -
Wt Distributing Hitch - Max Trailer Wt. 3500
Wt Distributing Hitch - Max Tongue Wt. 350
Maximum Trailering Capacity 3500
Frame Type Fully-boxed
Suspension Type - Front Independent
Suspension Type - Rear 2-Stage Multi-Leaf
Spring Capacity - Front 3500
Spring Capacity - Rear 3600
Axle Type - Front - TBD -
Axle Type - Rear - TBD -
Axle Capacity - Front 3500
Axle Capacity - Rear 3600
Axle Ratio (:1) - Rear 3.42
Stabilizer Bar Diameter - Front - TBD -
Stabilizer Bar Diameter - Rear - TBD -
Front Tire Order Code QIA
Rear Tire Order Code QIA
Spare Tire Order Code QDC
Front Tire Size 265/60R18
Rear Tire Size 265/60R18
Spare Tire Size T175/90D18
Front Tire Capacity - TBD -
Rear Tire Capacity - TBD -
Spare Tire Capacity - TBD -
Revolutions/Mile @ 45 mph - Front - TBD -
Revolutions/Mile @ 45 mph - Rear - TBD -
Revolutions/Mile @ 45 mph - Spare - TBD -
Front Wheel Size 18 x 8.5
Rear Wheel Size 18 x 8.5
Spare Wheel Size 18 x 4.5
Front Wheel Material Aluminum
Rear Wheel Material Aluminum
Spare Wheel Material Steel
Steering Type Electric Rack & Pinion
Steering Ratio (:1), On Center - TBD -
Steering Ratio (:1), At Lock - TBD -
Turning Diameter - Curb to Curb - TBD -
Turning Diameter - Wall to Wall - TBD -
Brake Type Pwr
Brake ABS System 4-Wheel
Disc - Front (Yes or ) Yes
Disc - Rear (Yes or ) Yes
Front Brake Rotor Diam x Thickness 13.4 x - TBD -
Rear Brake Rotor Diam x Thickness 13.3 x - TBD -
Fuel Tank Capacity, Approx 21.4
Fuel Tank Location - TBD -
Drivetrain Rear Wheel Drive
Fuel Economy Est-Combined 22 (2023)
EPA Fuel Economy Est - City 20 (2023)
EPA Fuel Economy Est - Hwy 25 (2023)
Engine Order Code L2R
Engine Type Turbocharged Gas I4
Displacement 2.7L/- TBD -
Fuel System Direct Injection
SAE Net Horsepower @ RPM 237 @ 5600
SAE Net Torque @ RPM 260 @ 1200-4000
Trans Order Code N8R
Trans Type 8
Trans Description Cont. Automatic
First Gear Ratio (:1) 4.56
Second Gear Ratio (:1) 2.97
Third Gear Ratio (:1) 2.08
Fourth Gear Ratio (:1) 1.69
Fifth Gear Ratio (:1) 1.27
Sixth Gear Ratio (:1) 1.00
Seventh Gear Ratio (:1) 0.85
Eighth Gear Ratio (:1) 0.65
Reverse Ratio (:1) 4.56
Cold Cranking Amps @ 0° F (Primary) 800
Maximum Alternator Capacity (amps) 170
Maximum Alternator Watts - TBD -
Total Cooling System Capacity - TBD -
Engine Displacement Units 2.7
Engine Camshaft DOHC
Engine Block Type aluminum
Engine Cylinder Count 4
Engine Valve Count 4
Passenger Capacity 5
Front Head Room 40.29
Front Leg Room 45.17
Front Shoulder Room 57.4
Front Hip Room 54.71
Second Head Room 38.28
Second Leg Room 34.7
Second Shoulder Room 56.13
Second Hip Room 53.09
Wheelbase 131.36
Length, Overall 213.21
Width, Max w/o mirrors 74.91 w/Mirrors Folded, 84.4 w/Mirrors
Height, Overall 78.79
Overhang, Front 34.51
Overhang, Rear w/o bumper 47.31
Front Bumper to Back of Cab - TBD -
Cab to Axle 23.4
Cab to End of Frame - TBD -
Ground to Top of Load Floor - TBD -
Ground to Top of Frame - TBD -
Frame Width, Rear - TBD -
Ground Clearance, Front 7.9
Ground Clearance, Rear 7.9
Cargo Box Length @ Floor 61.7
Cargo Box Width @ Top, Rear - TBD -
Cargo Box Width @ Floor 58.8
Cargo Box Width @ Wheelhousings 45.5
Cargo Box (Area) Height - TBD -
Tailgate Width - TBD -
Cargo Volume 41.9
Ext'd Cab Cargo Volume - TBD -
Basic Years 3
Basic Miles/km 36,000
Drivetrain Years 5
Drivetrain Miles/km 60,000
Drivetrain Note Certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles
Corrosion Years 6
Corrosion Miles/km 36,000
Roadside Assistance Years 5
Roadside Assistance Miles/km 60,000
Roadside Assistance Note Certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles
Maintenance Note First Visit: 12 Months/12,000 Miles
Starting From $29,500
Destination Charge $1,595
Gross Axle Wt Rating - Front 3500
Gross Axle Wt Rating - Rear 3600
Curb Weight - Front 2311
Curb Weight - Rear 1853
Gross Vehicle Weight Rating Cap 5800
Gross Combined Wt Rating 8700
Dead Weight Hitch - Max Trailer Wt. - TBD -
Dead Weight Hitch - Max Tongue Wt. - TBD -
Wt Distributing Hitch - Max Trailer Wt. 3500
Wt Distributing Hitch - Max Tongue Wt. 350
Maximum Trailering Capacity 3500
Frame Type Fully-boxed
Suspension Type - Front Independent
Suspension Type - Rear 2-Stage Multi-Leaf
Spring Capacity - Front 3500
Spring Capacity - Rear 3600
Axle Type - Front - TBD -
Axle Type - Rear - TBD -
Axle Capacity - Front 3500
Axle Capacity - Rear 3600
Axle Ratio (:1) - Rear 3.42
Stabilizer Bar Diameter - Front - TBD -
Stabilizer Bar Diameter - Rear - TBD -
Front Tire Order Code QHR
Rear Tire Order Code QHR
Spare Tire Order Code QDC
Front Tire Size 255/65R17
Rear Tire Size 255/65R17
Spare Tire Size T175/90D18
Front Tire Capacity - TBD -
Rear Tire Capacity - TBD -
Spare Tire Capacity - TBD -
Revolutions/Mile @ 45 mph - Front - TBD -
Revolutions/Mile @ 45 mph - Rear - TBD -
Revolutions/Mile @ 45 mph - Spare - TBD -
Front Wheel Size 17 x 8
Rear Wheel Size 17 x 8
Spare Wheel Size 18 x 4.5
Front Wheel Material Steel
Rear Wheel Material Steel
Spare Wheel Material Steel
Steering Type Electric Rack & Pinion
Steering Ratio (:1), On Center - TBD -
Steering Ratio (:1), At Lock - TBD -
Turning Diameter - Curb to Curb - TBD -
Turning Diameter - Wall to Wall - TBD -
Brake Type Pwr
Brake ABS System 4-Wheel
Disc - Front (Yes or ) Yes
Disc - Rear (Yes or ) Yes
Front Brake Rotor Diam x Thickness 13.4 x - TBD -
Rear Brake Rotor Diam x Thickness 13.3 x - TBD -
Fuel Tank Capacity, Approx 21.4
Fuel Tank Location - TBD -
Drivetrain Rear Wheel Drive
Fuel Economy Est-Combined 22 (2023)
EPA Fuel Economy Est - City 20 (2023)
EPA Fuel Economy Est - Hwy 25 (2023)
Engine Order Code L2R
Engine Type Turbocharged Gas I4
Displacement 2.7L/- TBD -
Fuel System Direct Injection
SAE Net Horsepower @ RPM 237 @ 5600
SAE Net Torque @ RPM 260 @ 1200-4000
Trans Order Code N8R
Trans Type 8
Trans Description Cont. Automatic
First Gear Ratio (:1) 4.56
Second Gear Ratio (:1) 2.97
Third Gear Ratio (:1) 2.08
Fourth Gear Ratio (:1) 1.69
Fifth Gear Ratio (:1) 1.27
Sixth Gear Ratio (:1) 1.00
Seventh Gear Ratio (:1) 0.85
Eighth Gear Ratio (:1) 0.65
Reverse Ratio (:1) 4.56
Cold Cranking Amps @ 0° F (Primary) 800
Maximum Alternator Capacity (amps) 170
Maximum Alternator Watts - TBD -
Total Cooling System Capacity - TBD -
Engine Displacement Units 2.7
Engine Camshaft DOHC
Engine Block Type aluminum
Engine Cylinder Count 4
Engine Valve Count 4
Passenger Capacity 5
Front Head Room 40.29
Front Leg Room 45.17
Front Shoulder Room 57.4
Front Hip Room 54.71
Second Head Room 38.28
Second Leg Room 34.7
Second Shoulder Room 56.13
Second Hip Room 53.09
Wheelbase 131.36
Length, Overall 213.02
Width, Max w/o mirrors 74.91 w/Mirrors Folded, 84.4 w/Mirrors
Height, Overall 78.79
Overhang, Front 34.51
Overhang, Rear w/o bumper 47.11
Front Bumper to Back of Cab - TBD -
Cab to Axle 23.4
Cab to End of Frame - TBD -
Ground to Top of Load Floor - TBD -
Ground to Top of Frame - TBD -
Frame Width, Rear - TBD -
Ground Clearance, Front 7.9
Ground Clearance, Rear 7.9
Cargo Box Length @ Floor 61.7
Cargo Box Width @ Top, Rear - TBD -
Cargo Box Width @ Floor 58.8
Cargo Box Width @ Wheelhousings 45.5
Cargo Box (Area) Height - TBD -
Tailgate Width - TBD -
Cargo Volume 41.9
Ext'd Cab Cargo Volume - TBD -
Basic Years 3
Basic Miles/km 36,000
Drivetrain Years 5
Drivetrain Miles/km 60,000
Drivetrain Note Certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles
Corrosion Years 6
Corrosion Miles/km 36,000
Roadside Assistance Years 5
Roadside Assistance Miles/km 60,000
Roadside Assistance Note Certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles
Maintenance Note First Visit: 12 Months/12,000 Miles
Starting From $35,200
Destination Charge $1,595
Gross Axle Wt Rating - Front 3500
Gross Axle Wt Rating - Rear 3600
Curb Weight - Front 2317
Curb Weight - Rear 1881
Gross Vehicle Weight Rating Cap 6000
Gross Combined Wt Rating 8700
Dead Weight Hitch - Max Trailer Wt. - TBD -
Dead Weight Hitch - Max Tongue Wt. - TBD -
Wt Distributing Hitch - Max Trailer Wt. 3500
Wt Distributing Hitch - Max Tongue Wt. 350
Maximum Trailering Capacity 3500
Frame Type Fully-boxed
Suspension Type - Front Independent
Suspension Type - Rear 2-Stage Multi-Leaf
Spring Capacity - Front 3500
Spring Capacity - Rear 3600
Axle Type - Front - TBD -
Axle Type - Rear - TBD -
Axle Capacity - Front 3500
Axle Capacity - Rear 3600
Axle Ratio (:1) - Front 3.42
Axle Ratio (:1) - Rear 3.42
Stabilizer Bar Diameter - Front - TBD -
Stabilizer Bar Diameter - Rear - TBD -
Front Tire Order Code QIA
Rear Tire Order Code QIA
Spare Tire Order Code QDC
Front Tire Size 265/60R18
Rear Tire Size 265/60R18
Spare Tire Size T175/90D18
Front Tire Capacity - TBD -
Rear Tire Capacity - TBD -
Spare Tire Capacity - TBD -
Revolutions/Mile @ 45 mph - Front - TBD -
Revolutions/Mile @ 45 mph - Rear - TBD -
Revolutions/Mile @ 45 mph - Spare - TBD -
Front Wheel Size 18 x 8.5
Rear Wheel Size 18 x 8.5
Spare Wheel Size 18 x 4.5
Front Wheel Material Aluminum
Rear Wheel Material Aluminum
Spare Wheel Material Steel
Steering Type Electric Rack & Pinion
Steering Ratio (:1), On Center - TBD -
Steering Ratio (:1), At Lock - TBD -
Turning Diameter - Curb to Curb - TBD -
Turning Diameter - Wall to Wall - TBD -
Brake Type Pwr
Brake ABS System 4-Wheel
Disc - Front (Yes or ) Yes
Disc - Rear (Yes or ) Yes
Front Brake Rotor Diam x Thickness 13.4 x - TBD -
Rear Brake Rotor Diam x Thickness 13.3 x - TBD -
Fuel Tank Capacity, Approx 21.4
Fuel Tank Location - TBD -
Drivetrain Four Wheel Drive
Fuel Economy Est-Combined 21 (2023)
EPA Fuel Economy Est - City 19 (2023)
EPA Fuel Economy Est - Hwy 23 (2023)
Engine Order Code L2R
Engine Type Turbocharged Gas I4
Displacement 2.7L/- TBD -
Fuel System Direct Injection
SAE Net Horsepower @ RPM 237 @ 5600
SAE Net Torque @ RPM 260 @ 1200-4000
Trans Order Code N8R
Trans Type 8
Trans Description Cont. Automatic
First Gear Ratio (:1) 4.56
Second Gear Ratio (:1) 2.97
Third Gear Ratio (:1) 2.08
Fourth Gear Ratio (:1) 1.69
Fifth Gear Ratio (:1) 1.27
Sixth Gear Ratio (:1) 1.00
Seventh Gear Ratio (:1) 0.85
Eighth Gear Ratio (:1) 0.65
Reverse Ratio (:1) 4.56
Transfer Case Model Autotrac
Transfer Case Gear Ratio (:1), High 1.00
Transfer Case Gear Ratio (:1), Low - TBD -
Transfer Case Power Take Off - TBD -
Cold Cranking Amps @ 0° F (Primary) 800
Maximum Alternator Capacity (amps) 170
Maximum Alternator Watts - TBD -
Total Cooling System Capacity - TBD -
Engine Displacement Units 2.7
Engine Camshaft DOHC
Engine Block Type aluminum
Engine Cylinder Count 4
Engine Valve Count 4
Passenger Capacity 5
Front Head Room 40.29
Front Leg Room 45.17
Front Shoulder Room 57.4
Front Hip Room 54.71
Second Head Room 38.28
Second Leg Room 34.7
Second Shoulder Room 56.13
Second Hip Room 53.09
Wheelbase 131.36
Length, Overall 213.21
Width, Max w/o mirrors 74.91 w/Mirrors Folded, 84.4 w/Mirrors
Height, Overall 78.79
Overhang, Front 34.51
Overhang, Rear w/o bumper 47.31
Front Bumper to Back of Cab - TBD -
Cab to Axle 23.4
Cab to End of Frame - TBD -
Ground to Top of Load Floor - TBD -
Ground to Top of Frame - TBD -
Frame Width, Rear - TBD -
Ground Clearance, Front 7.9
Ground Clearance, Rear 7.9
Cargo Box Length @ Floor 61.7
Cargo Box Width @ Top, Rear - TBD -
Cargo Box Width @ Floor 58.8
Cargo Box Width @ Wheelhousings 45.5
Cargo Box (Area) Height - TBD -
Tailgate Width - TBD -
Cargo Volume 41.9
Ext'd Cab Cargo Volume - TBD -
Basic Years 3
Basic Miles/km 36,000
Drivetrain Years 5
Drivetrain Miles/km 60,000
Drivetrain Note Certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles
Corrosion Years 6
Corrosion Miles/km 36,000
Roadside Assistance Years 5
Roadside Assistance Miles/km 60,000
Roadside Assistance Note Certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles
Maintenance Note First Visit: 12 Months/12,000 Miles
Starting From $37,300
Destination Charge $1,595
Gross Axle Wt Rating - Front 3500
Gross Axle Wt Rating - Rear 3600
Curb Weight - Front 2552
Curb Weight - Rear 1973
Gross Vehicle Weight Rating Cap 6250
Gross Combined Wt Rating 9100
Dead Weight Hitch - Max Trailer Wt. - TBD -
Dead Weight Hitch - Max Tongue Wt. - TBD -
Wt Distributing Hitch - Max Trailer Wt. 7700
Wt Distributing Hitch - Max Tongue Wt. 770
Maximum Trailering Capacity 7700
Frame Type Fully-boxed
Suspension Type - Front Independent
Suspension Type - Rear 2-Stage Multi-Leaf
Spring Capacity - Front 3500
Spring Capacity - Rear 3600
Axle Type - Front - TBD -
Axle Type - Rear - TBD -
Axle Capacity - Front 3500
Axle Capacity - Rear 3600
Axle Ratio (:1) - Front 3.42
Axle Ratio (:1) - Rear 3.42
Stabilizer Bar Diameter - Front - TBD -
Stabilizer Bar Diameter - Rear - TBD -
Front Tire Order Code Q2P
Rear Tire Order Code Q2P
Spare Tire Order Code XCQ
Front Tire Size 265/65R18
Rear Tire Size 265/65R18
Spare Tire Size 265/70R17
Front Tire Capacity - TBD -
Rear Tire Capacity - TBD -
Spare Tire Capacity - TBD -
Revolutions/Mile @ 45 mph - Front - TBD -
Revolutions/Mile @ 45 mph - Rear - TBD -
Revolutions/Mile @ 45 mph - Spare - TBD -
Front Wheel Size 18 x 8.5
Rear Wheel Size 18 x 8.5
Spare Wheel Size 17 x 8
Front Wheel Material Aluminum
Rear Wheel Material Aluminum
Spare Wheel Material Steel
Steering Type Electric Rack & Pinion
Steering Ratio (:1), On Center - TBD -
Steering Ratio (:1), At Lock - TBD -
Turning Diameter - Curb to Curb - TBD -
Turning Diameter - Wall to Wall - TBD -
Brake Type Pwr
Brake ABS System 4-Wheel
Disc - Front (Yes or ) Yes
Disc - Rear (Yes or ) Yes
Front Brake Rotor Diam x Thickness 13.4 x - TBD -
Rear Brake Rotor Diam x Thickness 13.3 x - TBD -
Fuel Tank Capacity, Approx 21.4
Fuel Tank Location - TBD -
Drivetrain Four Wheel Drive
Fuel Economy Est-Combined 19 (2023)
EPA Fuel Economy Est - City 17 (2023)
EPA Fuel Economy Est - Hwy 21 (2023)
Engine Order Code L3B
Engine Type Turbocharged Gas I4
Displacement 2.7L/- TBD -
Fuel System Direct Injection
SAE Net Horsepower @ RPM 310 @ 5600
SAE Net Torque @ RPM 430 @ 3000
Trans Order Code MFC
Trans Type 8
Trans Description Cont. Automatic
First Gear Ratio (:1) 4.56
Second Gear Ratio (:1) 2.97
Third Gear Ratio (:1) 2.08
Fourth Gear Ratio (:1) 1.69
Fifth Gear Ratio (:1) 1.27
Sixth Gear Ratio (:1) 1.00
Seventh Gear Ratio (:1) 0.85
Eighth Gear Ratio (:1) 0.65
Reverse Ratio (:1) 4.56
Transfer Case Model Autotrac
Transfer Case Gear Ratio (:1), High 1.00
Transfer Case Gear Ratio (:1), Low - TBD -
Transfer Case Power Take Off - TBD -
Cold Cranking Amps @ 0° F (Primary) 800
Maximum Alternator Capacity (amps) 170
Maximum Alternator Watts - TBD -
Total Cooling System Capacity - TBD -
Engine Displacement Units 2.7
Engine Camshaft DOHC
Engine Block Type aluminum
Engine Cylinder Count 4
Engine Valve Count 4
Passenger Capacity 5
Front Head Room 40.29
Front Leg Room 45.17
Front Shoulder Room 57.4
Front Hip Room 54.71
Second Head Room 38.28
Second Leg Room 34.7
Second Shoulder Room 56.13
Second Hip Room 53.09
Wheelbase 131.36
Length, Overall 213.21
Width, Max w/o mirrors 78.09 w/Mirrors Folded, 84.4 w/Mirrors
Height, Overall 79.83
Overhang, Front 34.51
Overhang, Rear w/o bumper 47.31
Front Bumper to Back of Cab - TBD -
Cab to Axle 23.3
Cab to End of Frame - TBD -
Ground to Top of Load Floor - TBD -
Ground to Top of Frame - TBD -
Frame Width, Rear - TBD -
Ground Clearance, Front 9.51
Ground Clearance, Rear 9.51
Cargo Box Length @ Floor 61.7
Cargo Box Width @ Top, Rear - TBD -
Cargo Box Width @ Floor 58.8
Cargo Box Width @ Wheelhousings 45.5
Cargo Box (Area) Height - TBD -
Tailgate Width - TBD -
Cargo Volume 41.9
Ext'd Cab Cargo Volume - TBD -
Basic Years 3
Basic Miles/km 36,000
Drivetrain Years 5
Drivetrain Miles/km 60,000
Drivetrain Note Certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles
Corrosion Years 6
Corrosion Miles/km 36,000
Roadside Assistance Years 5
Roadside Assistance Miles/km 60,000
Roadside Assistance Note Certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles
Maintenance Note First Visit: 12 Months/12,000 Miles
Starting From $32,800
Destination Charge $1,595
Gross Axle Wt Rating - Front 3500
Gross Axle Wt Rating - Rear 3600
Curb Weight - Front 2311
Curb Weight - Rear 1853
Gross Vehicle Weight Rating Cap 6000
Gross Combined Wt Rating 8700
Dead Weight Hitch - Max Trailer Wt. - TBD -
Dead Weight Hitch - Max Tongue Wt. - TBD -
Wt Distributing Hitch - Max Trailer Wt. 3500
Wt Distributing Hitch - Max Tongue Wt. 350
Maximum Trailering Capacity 3500
Frame Type Fully-boxed
Suspension Type - Front Independent
Suspension Type - Rear 2-Stage Multi-Leaf
Spring Capacity - Front 3500
Spring Capacity - Rear 3600
Axle Type - Front - TBD -
Axle Type - Rear - TBD -
Axle Capacity - Front 3500
Axle Capacity - Rear 3600
Axle Ratio (:1) - Front 3.42
Axle Ratio (:1) - Rear 3.42
Stabilizer Bar Diameter - Front - TBD -
Stabilizer Bar Diameter - Rear - TBD -
Front Tire Order Code QHR
Rear Tire Order Code QHR
Spare Tire Order Code QDC
Front Tire Size 255/65R17
Rear Tire Size 255/65R17
Spare Tire Size T175/90D18
Front Tire Capacity - TBD -
Rear Tire Capacity - TBD -
Spare Tire Capacity - TBD -
Revolutions/Mile @ 45 mph - Front - TBD -
Revolutions/Mile @ 45 mph - Rear - TBD -
Revolutions/Mile @ 45 mph - Spare - TBD -
Front Wheel Size 17 x 8
Rear Wheel Size 17 x 8
Spare Wheel Size 18 x 4.5
Front Wheel Material Steel
Rear Wheel Material Steel
Spare Wheel Material Steel
Steering Type Electric Rack & Pinion
Steering Ratio (:1), On Center - TBD -
Steering Ratio (:1), At Lock - TBD -
Turning Diameter - Curb to Curb - TBD -
Turning Diameter - Wall to Wall - TBD -
Brake Type Pwr
Brake ABS System 4-Wheel
Disc - Front (Yes or ) Yes
Disc - Rear (Yes or ) Yes
Front Brake Rotor Diam x Thickness 13.4 x - TBD -
Rear Brake Rotor Diam x Thickness 13.3 x - TBD -
Fuel Tank Capacity, Approx 21.4
Fuel Tank Location - TBD -
Drivetrain Four Wheel Drive
Fuel Economy Est-Combined 21 (2023)
EPA Fuel Economy Est - City 19 (2023)
EPA Fuel Economy Est - Hwy 23 (2023)
Engine Order Code L2R
Engine Type Turbocharged Gas I4
Displacement 2.7L/- TBD -
Fuel System Direct Injection
SAE Net Horsepower @ RPM 237 @ 5600
SAE Net Torque @ RPM 260 @ 1200-4000
Trans Order Code N8R
Trans Type 8
Trans Description Cont. Automatic
First Gear Ratio (:1) 4.56
Second Gear Ratio (:1) 2.97
Third Gear Ratio (:1) 2.08
Fourth Gear Ratio (:1) 1.69
Fifth Gear Ratio (:1) 1.27
Sixth Gear Ratio (:1) 1.00
Seventh Gear Ratio (:1) 0.85
Eighth Gear Ratio (:1) 0.65
Reverse Ratio (:1) 4.56
Transfer Case Model Autotrac
Transfer Case Gear Ratio (:1), High 1.00
Transfer Case Gear Ratio (:1), Low - TBD -
Transfer Case Power Take Off - TBD -
Cold Cranking Amps @ 0° F (Primary) 800
Maximum Alternator Capacity (amps) 170
Maximum Alternator Watts - TBD -
Total Cooling System Capacity - TBD -
Engine Displacement Units 2.7
Engine Camshaft DOHC
Engine Block Type aluminum
Engine Cylinder Count 4
Engine Valve Count 4
Passenger Capacity 5
Front Head Room 40.29
Front Leg Room 45.17
Front Shoulder Room 57.4
Front Hip Room 54.71
Second Head Room 38.28
Second Leg Room 34.7
Second Shoulder Room 56.13
Second Hip Room 53.09
Wheelbase 131.36
Length, Overall 213.02
Width, Max w/o mirrors 74.91 w/Mirrors Folded, 84.4 w/Mirrors
Height, Overall 78.79
Overhang, Front 34.51
Overhang, Rear w/o bumper 47.11
Front Bumper to Back of Cab - TBD -
Cab to Axle 23.4
Cab to End of Frame - TBD -
Ground to Top of Load Floor - TBD -
Ground to Top of Frame - TBD -
Frame Width, Rear - TBD -
Ground Clearance, Front 7.9
Ground Clearance, Rear 7.9
Cargo Box Length @ Floor 61.7
Cargo Box Width @ Top, Rear - TBD -
Cargo Box Width @ Floor 58.8
Cargo Box Width @ Wheelhousings 45.5
Cargo Box (Area) Height - TBD -
Tailgate Width - TBD -
Cargo Volume 41.9
Ext'd Cab Cargo Volume - TBD -
Basic Years 3
Basic Miles/km 36,000
Drivetrain Years 5
Drivetrain Miles/km 60,000
Drivetrain Note Certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles
Corrosion Years 6
Corrosion Miles/km 36,000
Roadside Assistance Years 5
Roadside Assistance Miles/km 60,000
Roadside Assistance Note Certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles
Maintenance Note First Visit: 12 Months/12,000 Miles
Starting From $40,200
Destination Charge $1,595
Gross Axle Wt Rating - Front 3500
Gross Axle Wt Rating - Rear 3600
Curb Weight - Front 2560
Curb Weight - Rear 1971
Gross Vehicle Weight Rating Cap 6250
Gross Combined Wt Rating 9100
Dead Weight Hitch - Max Trailer Wt. - TBD -
Dead Weight Hitch - Max Tongue Wt. - TBD -
Wt Distributing Hitch - Max Trailer Wt. 7700
Wt Distributing Hitch - Max Tongue Wt. 770
Maximum Trailering Capacity 7700
Frame Type Fully-boxed
Suspension Type - Front Independent
Suspension Type - Rear 2-Stage Multi-Leaf
Spring Capacity - Front 3500
Spring Capacity - Rear 3600
Axle Type - Front - TBD -
Axle Type - Rear - TBD -
Axle Capacity - Front 3500
Axle Capacity - Rear 3600
Axle Ratio (:1) - Front 3.42
Axle Ratio (:1) - Rear 3.42
Stabilizer Bar Diameter - Front - TBD -
Stabilizer Bar Diameter - Rear - TBD -
Front Tire Order Code QXP
Rear Tire Order Code QXP
Spare Tire Order Code XCQ
Front Tire Size 255/55R20
Rear Tire Size 255/55R20
Spare Tire Size 265/70R17
Front Tire Capacity - TBD -
Rear Tire Capacity - TBD -
Spare Tire Capacity - TBD -
Revolutions/Mile @ 45 mph - Front - TBD -
Revolutions/Mile @ 45 mph - Rear - TBD -
Revolutions/Mile @ 45 mph - Spare - TBD -
Front Wheel Size 20 x 9
Rear Wheel Size 20 x 9
Spare Wheel Size 17 x 8
Front Wheel Material Aluminum
Rear Wheel Material Aluminum
Spare Wheel Material Steel
Steering Type Electric Rack & Pinion
Steering Ratio (:1), On Center - TBD -
Steering Ratio (:1), At Lock - TBD -
Turning Diameter - Curb to Curb - TBD -
Turning Diameter - Wall to Wall - TBD -
Brake Type Pwr
Brake ABS System 4-Wheel
Disc - Front (Yes or ) Yes
Disc - Rear (Yes or ) Yes
Front Brake Rotor Diam x Thickness 13.4 x - TBD -
Rear Brake Rotor Diam x Thickness 13.3 x - TBD -
Fuel Tank Capacity, Approx 21.4
Fuel Tank Location - TBD -
Drivetrain Four Wheel Drive
Fuel Economy Est-Combined 19 (2023)
EPA Fuel Economy Est - City 17 (2023)
EPA Fuel Economy Est - Hwy 21 (2023)
Engine Order Code L3B
Engine Type Turbocharged Gas I4
Displacement 2.7L/- TBD -
Fuel System Direct Injection
SAE Net Horsepower @ RPM 310 @ 5600
SAE Net Torque @ RPM 430 @ 3000
Trans Order Code MFC
Trans Type 8
Trans Description Cont. Automatic
First Gear Ratio (:1) 4.56
Second Gear Ratio (:1) 2.97
Third Gear Ratio (:1) 2.08
Fourth Gear Ratio (:1) 1.69
Fifth Gear Ratio (:1) 1.27
Sixth Gear Ratio (:1) 1.00
Seventh Gear Ratio (:1) 0.85
Eighth Gear Ratio (:1) 0.65
Reverse Ratio (:1) 4.56
Transfer Case Model Autotrac
Transfer Case Gear Ratio (:1), High 1.00
Transfer Case Gear Ratio (:1), Low - TBD -
Transfer Case Power Take Off - TBD -
Cold Cranking Amps @ 0° F (Primary) 800
Maximum Alternator Capacity (amps) 170
Maximum Alternator Watts - TBD -
Total Cooling System Capacity - TBD -
Engine Displacement Units 2.7
Engine Camshaft DOHC
Engine Block Type aluminum
Engine Cylinder Count 4
Engine Valve Count 4
Passenger Capacity 5
Front Head Room 40.29
Front Leg Room 45.17
Front Shoulder Room 57.4
Front Hip Room 54.71
Second Head Room 38.28
Second Leg Room 34.7
Second Shoulder Room 56.13
Second Hip Room 53.09
Wheelbase 131.36
Length, Overall 213.21
Width, Max w/o mirrors 76.32 w/Mirrors Folded, 84.4 w/Mirrors
Height, Overall 79.58
Overhang, Front 34.5
Overhang, Rear w/o bumper 47.31
Front Bumper to Back of Cab - TBD -
Cab to Axle 23.4
Cab to End of Frame - TBD -
Ground to Top of Load Floor - TBD -
Ground to Top of Frame - TBD -
Frame Width, Rear - TBD -
Ground Clearance, Front 8.9
Ground Clearance, Rear 8.9
Cargo Box Length @ Floor 61.7
Cargo Box Width @ Top, Rear - TBD -
Cargo Box Width @ Floor 58.8
Cargo Box Width @ Wheelhousings 45.5
Cargo Box (Area) Height - TBD -
Tailgate Width - TBD -
Cargo Volume 41.9
Ext'd Cab Cargo Volume - TBD -
Basic Years 3
Basic Miles/km 36,000
Drivetrain Years 5
Drivetrain Miles/km 60,000
Drivetrain Note Certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles
Corrosion Years 6
Corrosion Miles/km 36,000
Roadside Assistance Years 5
Roadside Assistance Miles/km 60,000
Roadside Assistance Note Certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles
Maintenance Note First Visit: 12 Months/12,000 Miles
Starting From $46,800
Destination Charge $1,595
Gross Axle Wt Rating - Front 3500
Gross Axle Wt Rating - Rear 3400
Curb Weight - Front 2707
Curb Weight - Rear 2120
Gross Vehicle Weight Rating Cap 6350
Gross Combined Wt Rating 13250
Dead Weight Hitch - Max Trailer Wt. - TBD -
Dead Weight Hitch - Max Tongue Wt. - TBD -
Wt Distributing Hitch - Max Trailer Wt. 6000
Wt Distributing Hitch - Max Tongue Wt. 600
Maximum Trailering Capacity 6000
Frame Type Fully-boxed
Suspension Type - Front Independent
Suspension Type - Rear 2-Stage Multi-Leaf
Spring Capacity - Front 3500
Spring Capacity - Rear 3600
Axle Type - Front - TBD -
Axle Type - Rear - TBD -
Axle Capacity - Front 3500
Axle Capacity - Rear 3600
Axle Ratio (:1) - Front 3.42
Axle Ratio (:1) - Rear 3.42
Stabilizer Bar Diameter - Front - TBD -
Stabilizer Bar Diameter - Rear - TBD -
Front Tire Order Code QAF
Rear Tire Order Code QAF
Spare Tire Order Code RMR
Front Tire Size LT285/70R17
Rear Tire Size LT285/70R17
Spare Tire Size LT285/70R17
Front Tire Capacity - TBD -
Rear Tire Capacity - TBD -
Spare Tire Capacity - TBD -
Revolutions/Mile @ 45 mph - Front - TBD -
Revolutions/Mile @ 45 mph - Rear - TBD -
Revolutions/Mile @ 45 mph - Spare - TBD -
Front Wheel Size 17 x 8
Rear Wheel Size 17 x 8
Spare Wheel Size 17 x 8
Front Wheel Material Aluminum
Rear Wheel Material Aluminum
Spare Wheel Material Steel
Steering Type Electric Rack & Pinion
Steering Ratio (:1), On Center - TBD -
Steering Ratio (:1), At Lock - TBD -
Turning Diameter - Curb to Curb - TBD -
Turning Diameter - Wall to Wall - TBD -
Brake Type Pwr
Brake ABS System 4-Wheel
Disc - Front (Yes or ) Yes
Disc - Rear (Yes or ) Yes
Front Brake Rotor Diam x Thickness 13.4 x - TBD -
Rear Brake Rotor Diam x Thickness 13.3 x - TBD -
Fuel Tank Capacity, Approx 21.4
Fuel Tank Location - TBD -
Drivetrain Four Wheel Drive
Fuel Economy Est-Combined - TBD -
EPA Fuel Economy Est - City - TBD -
EPA Fuel Economy Est - Hwy - TBD -
Engine Order Code L3B
Engine Type Turbocharged Gas I4
Displacement 2.7L/- TBD -
Fuel System Direct Injection
SAE Net Horsepower @ RPM 310 @ 5600
SAE Net Torque @ RPM 430 @ 3000
Trans Order Code MFC
Trans Type 8
Trans Description Cont. Automatic
First Gear Ratio (:1) 4.56
Second Gear Ratio (:1) 2.97
Third Gear Ratio (:1) 2.08
Fourth Gear Ratio (:1) 1.69
Fifth Gear Ratio (:1) 1.27
Sixth Gear Ratio (:1) 1.00
Seventh Gear Ratio (:1) 0.85
Eighth Gear Ratio (:1) 0.65
Reverse Ratio (:1) 4.56
Transfer Case Model Autotrac
Transfer Case Gear Ratio (:1), High 1.00
Transfer Case Gear Ratio (:1), Low - TBD -
Transfer Case Power Take Off - TBD -
Cold Cranking Amps @ 0° F (Primary) 800
Maximum Alternator Capacity (amps) 220
Maximum Alternator Watts - TBD -
Total Cooling System Capacity - TBD -
Engine Displacement Units 2.7
Engine Camshaft DOHC
Engine Block Type aluminum
Engine Cylinder Count 4
Engine Valve Count 4
Passenger Capacity 5
Front Head Room 40.29
Front Leg Room 45.17
Front Shoulder Room 57.4
Front Hip Room 54.71
Second Head Room 38.28
Second Leg Room 34.7
Second Shoulder Room 56.13
Second Hip Room 53.09
Wheelbase 131.36
Length, Overall 212.69
Width, Max w/o mirrors 78.09 w/Mirrors Folded, 84.4 w/Mirrors
Height, Overall 81.8
Overhang, Front 33.98
Overhang, Rear w/o bumper 47.31
Front Bumper to Back of Cab - TBD -
Cab to Axle 23.3
Cab to End of Frame - TBD -
Ground to Top of Load Floor - TBD -
Ground to Top of Frame - TBD -
Frame Width, Rear - TBD -
Ground Clearance, Front 10.73
Ground Clearance, Rear 10.73
Cargo Box Length @ Floor 61.7
Cargo Box Width @ Top, Rear - TBD -
Cargo Box Width @ Floor 58.8
Cargo Box Width @ Wheelhousings 45.5
Cargo Box (Area) Height - TBD -
Tailgate Width - TBD -
Cargo Volume 41.9
Ext'd Cab Cargo Volume - TBD -
Basic Years 3
Basic Miles/km 36,000
Drivetrain Years 5
Drivetrain Miles/km 60,000
Drivetrain Note Certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles
Corrosion Years 6
Corrosion Miles/km 36,000
Roadside Assistance Years 5
Roadside Assistance Miles/km 60,000
Roadside Assistance Note Certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles
Maintenance Note First Visit: 12 Months/12,000 Miles
Use this shortened URL to share your current search results.
